SIB-VX Steam Boiler

Get a Price/Quote

SIB-VX Steam Boiler Specification

Life Span
15 Years

Voltage
415V / 3 Phase / 50 Hz

Fuel Consumption
15-120 kg/hr (depending on model)

Style
Horizontal

Output
Saturated Steam

Pressure
10.54 kg/cm (g)

Fuel Type
Oil Fired / Gas Fired

Capacity
300 kg/hr to 2000 kg/hr

Temperature
184C (approx)

Heat Efficiency
88% 2%

Condition
New

Material
Mild Steel

Part Type
Steam Generator

Dimension (L*W*H)
2800 mm x 1400 mm x 2100 mm

Function
Produce Saturated Steam for Industrial Use

Automation Grade
Semi-Automatic / Automatic

Chimney Height
6 meters (standard)

Shell Thickness
8-12 mm

Mounting Type
Floor Mounted

Color
Industrial Blue / Custom as required

Application
Dairy, Food Processing, Chemical, Pharmaceuticals, Textile, Rubber Industries

Control Panel
MS Powder Coated with Hooter & Indicators

Insulation Material
Glass Wool with Aluminium Cladding

Water Feeding System
Fully Automatic with Pump & Level Controller

About SIB-VX Steam Boiler

PRODUCTS FEATURES.

This is single pass dry back smock tube type vertical steam boilers.
Compact Skid mounted Pre-wired Pre-insulated Plug & Play unit: Compared to conventional boilers occupies very low foot print area
Advantage in S-IBR range: Relaxed norms. Eliminates need for certified boiler operators.
Compatible to condensate recovery: Accepts 100% condensate ensuring optimizing energy Utilization and Innovative steam separation mechanism. Simple and in expensive to install.

OPERATING RANGE:

Capacity : 100 kg/hr to 500 kg/hr.
Pressure : 7.00 kg/cm2
Firing fuels : coal/wood/gas/oil/Ele. Power

Engineered for Versatility and Efficiency

The SIB-VX Steam Boiler seamlessly serves industries from dairy to pharmaceuticals with its adaptable fuel options (oil/gas) and automated controls. Its high efficiency and durable construction ensure reliability in demanding environments, delivering saturated steam at approximately 184C and pressures of 10.54 kg/cm2 (g).

User-Friendly Automation and Controls

Equipped with a fully automatic water feed system, pump, level controller, and a robust MS powder-coated control panel (including hooter and indicators), the SIB-VX ensures safe, simplified, and uninterrupted operation for operators. The semi-automatic option is also available for specific process needs.

Built to Last in Industrial Settings

With a lifespan of 15 years, shell thickness of 8-12 mm, and glass wool insulation with aluminium cladding, this boiler is engineered for durability and minimal heat loss. Its floor-mounted design and custom dimensions provide flexibility for various plant layouts.

FAQ's of SIB-VX Steam Boiler:

Q: How does the water feeding system in the SIB-VX Steam Boiler work?

A: The SIB-VX is equipped with a fully automatic water feeding system, which uses a pump and level controller to maintain optimal water levels. This automated process ensures safe operation and reduces the need for manual monitoring.

Q: What are the typical applications for the SIB-VX Steam Boiler?

A: This steam boiler is widely used in dairy, food processing, chemical, pharmaceutical, textile, and rubber industries for producing saturated steam required for various industrial processes.

Q: When should I conduct maintenance on the SIB-VX Steam Boiler?

A: Regular preventive maintenance is recommended, such as monthly inspections of key components (pumps, level controllers, insulation) and annual professional servicing to maximize efficiency and extend the boiler's lifespan.

Q: Where can the SIB-VX Steam Boiler be installed?

A: Thanks to its floor-mounted, compact horizontal design and customizable color options, this boiler can be conveniently placed in industrial boiler rooms, process areas, or plant utility zones across India.

Q: What benefits does the glass wool with aluminium cladding insulation provide?

A: The glass wool insulation with aluminium cladding minimizes heat loss, increases energy efficiency, and helps maintain a safer operating temperature on the boiler's surface, contributing to lower operating costs.

Q: Which fuels are compatible with the SIB-VX Steam Boiler, and what is the typical consumption?

A: The SIB-VX can operate on both oil and gas fuels, accommodating fuel consumption rates that range from 15 kg/hr up to 120 kg/hr, depending on the specific model chosen.

Q: How does automation improve the operation of the SIB-VX Steam Boiler?

A: With automated water feeding, level control, and an integrated MS powder-coated control panel with indicators and alarms, the SIB-VX minimizes operator intervention, enhances safety, and ensures consistent steam output.
