Aquatherm Hot Water Boiler

Get a Price/Quote

Aquatherm Hot Water Boiler Specification

Life Span
12-15 years

Style
Vertical/Horizontal

Condition
New

Fuel Type
Oil / Gas / Electric

Capacity
100 LPH to 5000 LPH (Liters per hour)

Output
Hot Water

Voltage
220V / 380V

Heat Efficiency
Up to 86%

Pressure
6-10 Bar

Temperature
Up to 95C

Fuel Consumption
Depends on capacity and fuel type

Material
Mild Steel / Stainless Steel

Part Type
Hot Water Boiler

Dimension (L*W*H)
Customizable; Standard sizes available

Function
Provides hot water for industrial and commercial uses

Mounting
Floor Mounted

Color
Blue / Custom color available

Safety Features
Pressure relief valve, temperature cut-off

Corrosion Protection
Epoxy Painted Body

Usage Type
Industrial, Process Heating, Domestic Hot Water

Insulation Type
Glass Wool / Ceramic

Flow Rate
Adjustable

Installation
On-site installation available

Control Panel
Automatic with digital temperature controller

About Aquatherm Hot Water Boiler

The AQUATHERM series, horizontal three pass coil type packaged hot water boilers designed for maximum efficiency using a variety of liquid and gaseous fuels. It is designed with fuel flexibility in mind and can fire a range of heavy oils, light oils and gases. It allows low process temperatures without operating pressures. But also you can use this unit with pressurized hot water boilers.

Product Features

High capacity heating system
Multi-fuel option- heavy oils, light oils and gases
Rugged - requires very little maintenance
User-friendly systems.

Operating Range.

Capacities: From 0.1 million kcal/hr to 2.0 million kcal/hr
Temperature: Up to 90 deg C without pressure and with pressure up to 160 deg C
Firing fuels: Heavy oils, light oils and gases
Efficiency: Overall efficiency of 85 % (+/-2%) on NCV

Precision Engineered for Diverse Applications

The Aquatherm Hot Water Boiler is meticulously designed for industrial, process, and commercial hot water needs. Its adaptable vertical or horizontal style and customizable capacity range make it ideal for factories, hotels, hospitals, and housing complexes. The advanced safety systems and efficient insulation ensure reliable, energy-conscious performance.

Cutting-Edge Safety and Control Features

Equipped with a pressure relief valve, temperature cut-off, and an automatic digital control panel, the Aquatherm Boiler prioritizes operational safety and ease of use. Users can precisely manage water temperature and flow according to specific process or domestic requirements, ensuring consistent and secure operation.

Reliable Construction and Longevity

Crafted from high-quality mild steel or stainless steel, and protected with an epoxy finish, this robust boiler resists corrosion for a service life of 12-15 years. On-site installation and flexible sizing-standard or custom-ensure seamless integration into new or existing heating systems, making it a long-lasting solution.

FAQ's of Aquatherm Hot Water Boiler:

Q: How is the Aquatherm Hot Water Boiler installed on-site?

A: The Aquatherm Hot Water Boiler is floor mounted and can be installed on-site by our professional team or authorized partners. During installation, we ensure proper alignment, connection to utilities, and thorough system testing to guarantee safe and efficient operation.

Q: What types of insulation are available with this boiler?

A: This boiler model offers either glass wool or ceramic insulation options, both designed to effectively minimize heat loss and optimize energy efficiency for demanding industrial or commercial environments.

Q: When should I use this hot water boiler for process heating needs?

A: The Aquatherm Hot Water Boiler is suitable whenever consistent hot water supply is vital, such as in industrial process heating, commercial laundering, or large-scale domestic systems. Select your required temperature and flow rate for each specific application.

Q: Where can the Aquatherm Hot Water Boiler be used?

A: It is built for use in various environments, including factories, manufacturing facilities, hotels, hospitals, and residential buildings requiring reliable hot water for different processes or amenities.

Q: What safety features are integrated into this hot water boiler?

A: For enhanced operational safety, the boiler incorporates a pressure relief valve and a temperature cut-off device, in addition to digital temperature controls, helping prevent overpressure and overheating during use.

Q: How does adjustable flow rate benefit my application?

A: The adjustable flow rate enables precise control over hot water output, allowing users to customize performance for varying industrial processes or fluctuating domestic demands, thereby improving overall efficiency and resource management.

Q: What are the advantages of epoxy painted body and corrosion protection?

A: The epoxy painted body shields the boiler against moisture and corrosive substances common in industrial environments, enhancing durability and preserving performance across its 12-15 year lifespan.
